Specifications
- Product model C450F
- Detector type Vanadium oxide uncooled focal plane detector
- Effective pixels 384 (H) × 288 (V)
- Pixel pitch 12 μm
- Spectral range 8 μm～14 μm
- Sensitivity (NETD) ≤30 mK@f/ 1.0
- Frame rate 50 Hz
- Focal length 50 mm
- Field of view H: 5.5°; V: 4.1°
- Thermal focus control Manual
- Close focusing distance 5 m (16.40 ft)
- Aperture F1.0
- Detection Range 2600 m (8530.18 ft)
- Digital zoom 1 ×; 2 ×; 4 ×; 8 ×
- Magnification 1.0X
- 6 colour palettes (white hot/ black hot/ yellowish red/ warning signal/ amber/ amber brown)
- Display screen size 0,41 inch, OLED
- Built-in EMMC (32 GB)
- Uniformity correction Automatic, manual
- PIP YES
- Audio recording YES
- Recording with recall activation YES
- Max. Recall 1000g/ 1ms
- Hotspot tracking Yes
- Wi-Fi Yes
- Power supply 5 VDC/ 1 A, USB Type-C
- Battery type 1 rechargeable lithium battery
- Battery capacity 3200 mAh
- Surge protection Yes
- Battery life ≥7.5 h
- Operating temperature -30 °C to +55 °C (-22 °F to +131 °F)
- Storage temperature -30 °C to +65 °C (-22 °F to +149 °F)
- Protection IP67
- Product dimensions 190.8 mm × 64.1 mm × 87.7 mm (7.51)
- Package dimensions 267 mm × 227 mm × 116 mm (10,51)
- Net weight ≤620 g (without battery)
Description:
High Shock Resistance
The rugged structure is designed to withstand a maximum recoil of over 6,000 joules, perfect for a variety of rifle with calibers of 12 gauge, 9.3×64, .375H&H, etc.
Pro-grade Image Sensor
All models adopt 12μm detector, up to 384×288 resolution, detector sensitivity < 30mk, even in heavy rain, fog or cold harsh environment, can perfectly present details, clearly observe the target feature details.
Easy on Your Hand, Simplified Operation
The Chiron series has a rotary knob design to help you quickly operate the menu for a more convenient and fast operating experience.
Ultra-low Latency
Hunting is all about “The moment,” so there must be no error between what you see on your device‘s display and where your target actually is. PIPS（ Pixfra Imaging Processing Solution ） allows image latency of less than 20ms, compared to 60ms with conventional image solutions, which will help you to accurately aim at the target.
Pre For the Magic Moment
Chiron supports Recoil Activated Recording (RAR), it automatically records key moments as you shoot, so you don’t miss any of the highlights. With the Pixfra APP, you can also quickly share videos with your friends.
