Specification:
| Resolution |
640x512 |
| Pixel pitch |
12µm |
| NETD |
25mk@300k |
| Spectral range |
8-14µm |
| Frame rate |
50HZ |
| Objective lens |
35mm/F0.9 70mm/F1.0Dual FOV |
| Field of view |
12.5°x10.0 / 6.3°x5.0° |
| Magnification |
2.0X-4.0X |
| Digital zoom |
1-6X continuous zoom |
| Eye relief |
40mm |
| Exit pupil |
6mm |
| Diopter |
±5D |
| Display type |
AMOLED |
| Resolution |
1024x768 |
| Display size |
0.39 inch |
| Color palette |
6 |
| Image model |
WDR (Wide Dynamic Range) Mode; Object Mode (Object enhanced) |
| Photo/video playback |
Yes |
| Language |
Multiple-languages |
| Reticle |
7, adjustment coordinates |
| Built-in memory |
32GB |
| PIP |
Yes |
| AI/MIL distance measurement |
Yes |
| Heat track |
Yes |
| GPS |
Yes |
| Real-time notification |
Yes |
| Internal battery |
Internal high capacity lithium ion (18650x2) |
| Battery life |
Continuous working time ≥12h |
| Type-C |
Supports battery charging, data transfer and analog video output |
| WI-FI |
Two-way Wi-Fi connection; App remote control |
| Working temperature |
-20℃—+50℃ |
| Protection level |
IP67 |
| Weight, g |
780 |
| Size, mm |
288x83x83 |
| External cable |
Analog video cable; USB data cable |
| Other accessories |
Wrist strap; plush bag; user manual |
Dual-Field of View with 2x Optical Zoom
A wide FOV with a focal length of 20/25mm can be used for detection; A narrow FOV with a focal length of 40/50mm can be used for identification.
High-Precision Zoom
1.0-6.0X HD zooming ensures excellent sharpness and the highest resolution of details from minimum to maximum magnification.
12 Hours of Work on a Single Charge
Built-in battery with 12H super long capacity, which ensures a pleasant and dedicated outdoor experience without worry.
Joystick Control
The well-designed joystick performs an easy operation on menu operations by toggling the button in any direction.
IP67 Protection Rate
Provided with IP67-rated weatherproof performance, it is protected from heavy rainfall, snow, smoke, smog, or dust.
Lightweight and Compact Size
The compact dimension makes it a lightweight and handy companion wherever you go.
Long Detection Range
Detection range up to 5500m
Two Image Modes
Designed with both WDR mode and target mode, it captures details clearly under different scenarios as needed. WDR Mode is suitable for high-contrast lighting conditions, while Target Mode helps you to focus more on your targets.
Built-in AI Rangefinder
Based on deep learning algorithm, the object distance can be automatically measured.
Electronic Image Stabilization
It provides clear and precise images even in scenes with lots of motion.
Wide Options of Color Palettes
6 thermal image pallets with comfortable visual experience, to meet with a variety of environments and weather conditions.
Photo/Video Recorder
Integrated pictures and video recording makes sharing the thermal action quick and easy, with the functions of playback and APP sharing.
GPS Function
Enable users to know their coordinates in real time, which makes field activities safer.
Light and Handy
The compact dimension makes it a lightweight and handy companion wherever you go.
