Specification:
| Resolution, pixel |
640x512/12 |
| Spectral |
8-14µm |
| NETD |
≤25mk |
| Frame rate |
50Hz |
| Objective lens |
20/60mm,F/1.0 |
| Field of view |
21.7°x17.4°/ 7.3°x5.9° |
| Magnification |
1.1x/3.2x |
| Digital zoom |
1-5X continuous zoom |
| Eye relief |
45mm |
| Exit pupil |
6mm |
| Diopter |
-5 ~ +5 |
| Click range, m @100 m (H/V) |
3,6m/3,6m |
| Reticle |
7 |
| Rectile color |
Black and white |
| Display type |
AMOLED |
| Resolution, pixel |
1024x768 |
| Display size |
0.39 inch |
| Color palette |
6 |
| Max. recoil power on rifled weapon |
6000J |
| Mounting brackets on weapon |
Standard Picatinny Rail |
| Shooting record |
Support |
| RAV |
Yes |
| Auto zeroing |
Yes |
| Manual zeroing |
Yes |
| Zeroing profiles |
5 |
| Picture-in-picture |
Yes |
| Image calibration |
Via lens cover |
| Photo/video playback |
Yes |
| Inbuilt memory |
64G |
| Magnetic interface |
Data transfer |
| Wi-Fi |
Yes |
| Replaceable battery |
18650x2 |
| Battery reverse connection |
Yes |
| Battery life |
14h |
| Operating temperature |
-20℃—+50℃ |
| IP rating |
IP67 |
| Weight, g |
880 |
| Size, mm |
220x84x87 |
| Magnetic cable |
Magnetic interface data cable |
| Other Accessory |
Standard Picatinny Rail, eyeshade and etc. |
Highly Sensitive Detector
Thermal imaging sensor with NETD ≤25mK and 12µm detector ensures perfect detail recognition.
Non-Shutter Correction Technology
Invisible, background calibration means the screen will never freeze and there is no noisy shutter to alert your quarry
Laser Rangefinder with Ballistic Calculator
The laser rangefinder with ballistic calculator realize a long range targets measurement and an accurate shooting.
Automatic Zeroing
The automatic zeroing function makes it smart to adjust the reticle and take a shot.
Recoil Activated Video (RAV)
With RAV, it records videos of before, during, and after your shot, and captures the footage of your hunting moments.
Lightweight & Compact Size
The compact dimension makes it a light and handy companion wherever you go.
Long Detection Range
Maximum 60mm objective lens and advanced algorithm, boast exceptional detection range of up to 3,000 meters in complete darkness.
More Advantages
HD AMOLED Display
The 1024x768 HD AMOLED display offers improved color rendering, energy efficiency, high contrast, and rapid response, delivering clear and smooth visuals in dark environments.
High-Precision Zoom
1.0-5.0X HD zooming ensures excellent sharpness and the highest resolution of details from minimum to maximum magnification.
Long Battery Life
Up to 14 hours of active use. No more lost exciting moments due to drained batteries.
Real-time APP Notification
The “Smart Thermal” APP can instantly pop up a notification while the monocular detecting and identifying the target to avoid any distraction.
IP67 Waterproof
Provided with IP67-rated weatherproof performance, it is protected from heavy rainfall, snow, smoke, smog, or dust.
