Vector Optics Paragon 1×16 Micro Prism Scope – True 1× CQB Prism with Ultra-Wide Field of View
The Vector Optics Paragon 1×16 Micro Prism Scope (SCPS-M01) delivers true one-power, distortion-free performance for both-eyes-open shooting. Featuring an ultra-wide 14.5° field of view and a crystal-clear FMC prism, this compact optic is built for lightning-fast target acquisition in close to medium-range engagements. Designed around the .223/5.56×45 mm cartridge, it is the ultimate choice for modern carbines and AR platforms.
Main Features
- True 1× Magnification: Ideal for CQB and rapid transitions between targets
- Objective Lens: 16 mm fully multi-coated (FMC) for maximum clarity and light transmission
- Prism Design: Distortion-free, edge-to-edge imaging with large eye box for fast sight picture acquisition
- Eye Relief: 76 mm (3.0 in) for comfortable shooting with any stance
- Field of View: 14.5° — wider than most other micro prisms on the market
- Reticle: 2 MOA center dot with surrounding ring for rapid acquisition; etched glass remains visible without illumination
- Illumination: 10 brightness levels from very bright to NV-compatible ultra-low settings
- Adjustments: 1 MOA click values, >40 MOA windage & elevation range
- Durability: Rugged 6061-T6 aluminum housing, IP67 waterproof (1 m for 30 min), nitrogen-filled fog-proof, and 1000 G shock-proof
- Mounting: Absolute co-witness height for perfect alignment with AR-15 iron sights
- Length & Weight: Only 75 mm (3.0 in) long, 220 g (7.8 oz) for minimal front-end weight
Real-World Applications
Close Quarters Battle (CQB)
The true 1× magnification allows shooters to engage targets with both eyes open, enhancing situational awareness and speed in tight spaces. The large eye box and wide FOV make it easy to stay on target during rapid movement.
Dynamic Competition Shooting
Perfect for 3-Gun and action rifle sports, the Paragon 1×16 delivers quick sight picture acquisition, precise aiming with its 2 MOA dot, and consistent performance under fast transitions.
Patrol & Duty Use
Its rugged, waterproof, and shock-resistant design ensures reliability in all weather and operational environments, while NV-compatible illumination supports night operations.
Optical & Mechanical Excellence
- Fully Multi-Coated Optics: Maximizes brightness and clarity in all lighting conditions
- Etched Reticle: Always visible, even with illumination turned off—reliable in battery-failure scenarios
- NV-Compatible: Two ultra-low illumination settings pair with night vision devices for stealth shooting
- Compact Strength: CNC-machined from aerospace-grade aluminum with precision alignment for repeatable accuracy
Included Accessories
- Integrated Picatinny mount
- Riser section for height adjustment
- Honeycomb sunshade
- Lens covers
- Adjustment tool and hex keys
- Lens cleaning cloth
Technical Specifications
| Specification |
Details |
| Magnification |
1× (true one power) |
| Objective Lens |
16 mm, fully multi-coated |
| Eye Relief |
76 mm (3.0 in) |
| Field of View |
14.5° / 25.4 m @ 100 m |
| Reticle |
Etched 2 MOA dot with ring |
| Illumination |
10 levels, NV compatible |
| Adjustment Increment |
1 MOA per click |
| Adjustment Range |
>40 MOA windage & elevation |
| Length |
75 mm (3.0 in) |
| Weight |
220 g (7.8 oz) |
| Housing |
6061-T6 aluminum |
| Waterproof Rating |
IP67 |
| Shock Resistance |
1000 G |
| Mount |
Picatinny, absolute co-witness |
| Battery |
CR2032 (not included) |
| Included Accessories |
Riser, sunshade, covers, tools, cloth |
Summary
The Vector Optics Paragon 1×16 Micro Prism Scope is a purpose-built CQB optic combining unmatched field of view, fast acquisition capabilities, and rock-solid durability. With true one-power clarity, etched illuminated reticle, and compact rugged housing, it is a must-have for competitive shooters, tactical operators, and patrol use where speed and precision are paramount.
