Aircraft
|
|
|
Takeoff Weight (Without Accessories)
|
EVO II Pro Enterprise：2.45lbs (1110g) |
|
EVO II Dual 640T Enterprise：2.51lbs (1136.5g) |
| Diagonal Length |
16.8in (427mm) |
| Max Flight Time (no wind) |
42min（without accessories） |
| Hovering Time (no wind) |
38min（with strobe） |
|
29min（with spotlight） |
|
34min（with loudspeaker） |
|
36min（with RTK module） |
| Max Level Flight Speed |
45 mph (20 m/s) (Ludicrous) |
| Max Ascent Speed |
18 mph (8 m/s (Ludicrous) |
| Max Descent Speed |
9 mph (4 m/s) (Ludicrous) |
| Max Service Ceiling Altitude |
4.3 miles (7000 m) MSL |
| Operating Temperature |
14℉ to 104℉ (-10℃ to 40℃) |
| Max Wind Speed Resistance |
12 m/s (Take-off and landing) |
| Operating Frequency |
2.400GHz - 2.4835GHz；5.725GHz - 5.850GHz |
| Hovering Accuracy Range |
Vertical: |
|
± 0.3ft (0.1m) (with RTK) |
|
± 0.3ft (0.1m) (with Vision Positioning) |
|
± 1.6ft (0.5m) (with GPS Positioning) |
|
Horizontal: |
|
± 0.3ft (0.1m) (with RTK) |
|
± 0.9ft (0.3m) (with Vision Positioning) |
|
± 4.9ft (1.5m) (with GPS Positioning) |
|
Gimbal
|
|
|
Mechanical Range
|
Pitch: -135° to +45° |
|
Yaw: -100° to +100° |
| Operation Range |
Pitch: -90° to +30° |
| Stability |
More Stable with 3 Axies |
| Max Control Speed (Tilt) |
300°/s |
| Angular Vibration Range |
±0.005° |
|
Sensing System
|
|
|
Sensing System Type
|
Omnidirectional Binocular Sensing System |
| Forward |
Accurate Measuring Range: 1.6 – 65ft (0.5 - 20m) |
|
Detection Range: 1.6 – 131ft (0.5 - 40m) |
|
Effective Sensing Speed: < 33mph (15m/s) |
|
FOV: Horizontal: 60°, Vertical: 80° |
| Backward |
Accurate Measuring Range: 1.6 – 52ft (0.5 - 16m) |
|
Detection Range: 1.6 – 104ft (0.5 - 32m) |
|
Effective Sensing Speed: < 26mph (12m/s) |
|
FOV: Horizontal: 60°, Vertical: 80° |
| Upward |
Accurate Measuring Range: 1.6 – 39ft (0.5 - 12m) |
|
Detection Range: 1.6 – 78ft (0.5 - 24m) |
|
Effective Sensing Speed: < 13mph (6m/s) |
|
FOV: Horizontal: 65°, Vertical: 50° |
| Downward |
Accurate Measuring Range: 1.6 – 36ft (0.5 - 11m) |
|
Detection Range: 1.6 – 72ft (0.5 - 22m) |
|
Effective Sensing Speed: < 13mph (6m/s) |
|
FOV: Horizontal: 100°, Vertical: 80° |
| Sides |
Accurate Measuring Range: 1.6 – 39ft (0.5 - 12m) |
|
Detection Range: 1.6 – 78ft (0.5 - 24m) |
|
Effective Sensing Speed: < 22mph (10m/s) |
|
FOV: Horizontal: 65°, Vertical: 50° |
| Service Environment |
Forward, Backward, and Sides: |
|
Surface with clear pattern and adequate lighting (lux > 15) |
|
Upward: |
|
Detects diffuse reflective surfaces (>20%) |
|
(walls, trees, people, etc.) |
|
Downward: |
|
Surface with clear pattern and adequate lighting (lux > 15) |
|
Detects diffuse reflective surfaces (>20%) |
|
(walls, trees, people, etc.) |
|
EVO II Pro Enterprise Camera
|
|
|
Sensor
|
1-inch CMOS; 20 million effective pixels |
| FOV |
82° |
| Aperture |
f/2.8 - f/11 |
| Focus Range |
1m to ∞ |
| Equivalent Focal Length |
28.6mm |
| ISO Range |
Video: 100-6400 (auto) |
|
Photo: 100-3200 (auto) |
| Zoom |
1-16x (up to 3x lossless zoom) |
| Still Photography Modes |
Single Shot |
|
Burst shooing: 3/5 frames |
|
Automatic Exposure Bracketing (AEB)： |
|
3/5 bracketed frames at 0.7 EV Bias |
|
Timelapse： |
|
JPG：2s/5s/7s/10s/20s/30s/60s |
|
DNG：5s/7s/10s/20s/30s/60s |
|
HyperLight：support (under 4K JPEG format） |
|
Long Exposure: Max 8s |
|
HDR imaging: (under 4K JPEG) |
| Still Photography Resolution |
5472*3648 (3:2) |
|
5472*3076 (16:9) |
|
3840*2160 (16:9) |
| Video Format |
MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265) |
| Video Resolution |
6K 5472*3076 p30/p25/p24 |
|
4K 3840*2160 p60/p50/p48/p30/p25/p24 |
|
2.7K 2720*1528 p120/p60/p50/p48/p30/p25/p24 |
|
1080p 1920*1080 p120/p60/p50/p48/p30/p25/p24 |
| Max Bitrate |
120Mbps |
|
EVO II Dual 640T Enterprise Thermal Camera
|
|
|
Sensor
|
Vanadium oxide uncooled infrared focal plane detector |
| Viewing Angle |
H33°V26° |
| Sensor resolution |
640x512 |
| Pixel Pitch |
12μm |
| Focal Length |
13mm |
| Wavelength range |
8～14μm |
| Accurate temperature measurement distance |
2-20 meters |
| Temperature measurement accuracy |
±3℃ or ±3% of reading (whichever is greater) |
|
@ambient temperature -20℃~60℃ |
| Temperature range |
High gain mode: -20° to +150°C |
|
Low gain mode: 0° to +550°C |
| Zoom |
1-16x |
| Photo shooting mode |
Single shooting, continuous shooting,time-lapse shooting |
| Camera resolution |
Infrared mode: 640*512 |
|
Picture in Picture: 1920*1080, 1280*720 |
| Video Resolution |
640*512 30fps |
| Video format |
MOV / MP4 (support H.264/H.265) |
|
EVO II Dual 640T Enterprise Visual Camera
|
|
|
Sensor
|
1/2 inch CMOS; 48M effective pixels |
| FOV |
FOV：79° |
| Aperture |
f/1.8 |
| Focus range |
0.5m to ∞ |
| Equivalent Focal Length |
25.6mm |
| ISO Range |
Video: 100-6400 (auto) |
|
Photo: 100-3200 (auto) |
| Zoom |
1-16x (up to 4x lossless zoom) |
| Still Photography Modes |
Single Shot |
|
Burst shooing: 3/5 frames |
|
Automatic Exposure Bracketing (AEB)： |
|
3/5 bracketed frames at 0.7 EV Bias |
|
Timelapse： |
|
JPG：2s/5s/7s/10s/20s/30s/60s |
|
DNG：5s/7s/10s/20s/30s/60s |
|
HyperLight：support (under 4K JPEG format） |
|
Long Exposure: Max 8s |
|
HDR imaging: (under 4K JPEG) |
| Still Photography Resolution |
8000*6000 (4:3) |
|
7680*4320 (16:9) |
|
4000*3000 (4:3) |
|
3840*2160 (16:9) |
| Video Format |
MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265) |
| Video Resolution |
8K 7680*4320 p25/p24 |
|
6K 5760*3240 p30/p25/p24 |
|
4K 3840*2160 p60/p50/p48/p30/p25/p24 |
|
2.7K 2720*1528 p120/p60/p50/p48/p30/p25/p24 |
|
1080P 1920*1080 p120/p60/p50/p48/p30/p25/p24 |
| Max Bitrate |
120Mbps |
|
Remote Controller
|
|
|
*Operating Frequency
|
902-928 MHz; 2.400-2.4835 GHz; 5.725-5.850 GHz |
| Max Transmission Distance(unobstructed, free of interference) |
FCC: 13km |
|
CE: 7km |
| Transmitter Power (EIRP) |
902-928 MHz |
|
FCC:≤30dBm |
|
2.400-2.4835 GHz |
|
FCC:≤30dBm |
|
CE：≤20dBm |
|
5.725-5.850 GHz |
|
CE：≤14dBm |
| Internal Storage |
128GB |
| Video Output Port |
HDMI |
| Built-in Battery |
Name: Intelligent Li-ion battery |
|
Capacity：5800mAh |
|
Voltage：11.55V |
|
Battery Type：Li-ion |
|
Battery Energy：67 Wh |
|
Charging time：120 min |
| Battery Life |
3hr (Max. intensity) |
|
4.5hr (50% intensity) |
| Operating Temperature |
-20℃ - 40℃ |
| RC Size |
303×190×87mm(Ant. folded) |
|
303 x 273 x 87 mm (Ant. unfolded) |
